UM high energy vertical bead mill （sand mill）
> > > >
UM high energy vertical bead mill （sand mill）
UM high energy vertical bead mill （sand mill）
UM high energy vertical bead mill （sand mill）
UM high energy vertical bead mill （sand mill）
Contact Us Request a quote
  • Introduction
  • Application
  • Features
  • Key benefits
  • Technical data
1.Product inlet from the top
2.Outer plus inner peg milling annulus
3.Power input by forced displacement of media in the range 0,1 - 1,5
4.Predispersing zone
5.Internal media recirculation
6.Media separation by centrifuging without screen
7.High efficiency cooling of rotor, outer and inner stator + bottom
Application
NC-printing Inks
special liquid printing inks
tinting pastes for coatings
inkjet
nano product
automotive refinish & OEM
Industrial multi-purpose coatings
electronic paste
  • vertical bead mill
  • 标题
  • control panel
  • in packing
Features
1.high energy density mill
2.internal media recirculation
3.high flow rate product recirculation
4.discrete pass option
5.full production size mill
6. times smaller than conventional mill
7.frequency inverter drive
8.plc - based automation package
  • alumina
  • ceramic ink
  • coatings
  • Inkjet ink
  • lithium
  • nano-material
  • nitrile glove
  • Pharmaceutics
Key benefits
power input primarily by turbulent displacement of media
for demanding true grinding and dispersing applications
high flow rate capability by internal media recirculation
grinding media separation by centrifugal forces
outstandingly suitable for recirculation grinding
excellently suitable for 1-pass grinding with high flow rate
linear scale-up with temperature sensitive products

Technical data


Model

Grinding Chamber
Volume
L

Power
kW

Batch
L

Max
.Tip
Speed

UM02

0.2

2.2

0.5-1

10-16

UM05

0.5

3.7

1-5

10-16

UM2

2

5.5/7.5

3~20

10-16

UM6

6

18.5/22

20-200

10-16

UM15

16

45/55

150-1000

10-16

UM30

30

75/95

150-2000

10-16

UM60

60

160

300-3000

10-16


NC-printing Inks

special liquid printing inks

tinting pastes for coatings

inkjet

nano product

automotive refinish & OEM

Industrial multi-purpose coatings

electronic paste

1.high energy density mill
2.internal media recirculation
3.high flow rate product recirculation
4.discrete pass option
5.full production size mill
6. times smaller than conventional mill
7.frequency inverter drive
8.plc - based automation package
power input primarily by turbulent displacement of media
for demanding true grinding and dispersing applications
high flow rate capability by internal media recirculation
grinding media separation by centrifugal forces
outstandingly suitable for recirculation grinding
excellently suitable for 1-pass grinding with high flow rate
linear scale-up with temperature sensitive products

Model

Grinding Chamber
Volume
L

Power
kW

Batch
L

Max
.Tip
Speed

UM02

0.2

2.2

0.5-1

10-16

UM05

0.5

3.7

1-5

10-16

UM2

2

5.5/7.5

3~20

10-16

UM6

6

18.5/22

20-200

10-16

UM15

16

45/55

150-1000

10-16

UM30

30

75/95

150-2000

10-16

UM60

60

160

300-3000

10-16
